 Solution types include regular solution, ultra-long-screen solution, and splicing screen solution.

          Image Modified

Note:

The rotating screen solution is displayed only when the user account has permission.

...

          • Only regular screen solutions support intelligent tag matching.
          • Turning on intelligent tag matching allows a solution to be automatically published to the screens with the same tags as the solution. Please note that the solution cannot be added to schedules.
          • When a solution with tags is published to a player with the same tags, to ensure accurate matching, it needs to correspond with the player SN.

    The solution editor is displayed.

...

Step 3 Edit the solution on the solution editor.

After a solution is added, it can be immediately previewed in real time to ensure the content accuracy and playback effect.

Image Added

Table 3-2 Solution editor description

No.FunctionDescription
1

Set basic information

View the solution type and name, edit the solution name and resolution, and select screens to be associated.

2

Add media

Click a media icon to add the corresponding type of media to the page media editing area.
3

View beginner’s guide, and preview, save and publish solutions

View beginner’s guide, and preview, save and publish solutions.

4

Edit media and pages

Edit media and pages.

  • Media: Adjust media order and delete media.
    • Click the up/down buttons or drag media to change the layer order.
    • Media includes media types such as images, videos, mixed media, and documents, which can be adjusted in playback order by clicking the up/down buttons or manually dragging the media.
  • Page: Add, copy and delete pages, and adjust the page order.

Pages play sequentially from top to bottom.

5

Edit page media

Zoom pages in or out, delete media and change media layer order and layout. Batch operations are supported. A text widget can be added by double-clicking the blank area.

Users can copy media (including its properties) from other pages and paste the media to the current page.

  • You can undo at most 5 steps.
    • You can redo at most 5 steps

    .

    6

    Edit properties

    Edit the properties of widgets and pages.

    Widget properties: Widgets are the media items added to a page. The properties of different widgets vary. Select a widget before editing its properties.

    Page properties: Specify the validity range, play count, and schedule for a page.

    • Validity Range: If this option is selected, Start Date and End Date will be displayed. Expired pages will be skipped during solution playback.
    • Times to Play: Specifies the number of times to play the page continuously.
    • Schedule: Specifies the time and interval to play a page. If there are overlapping timeslots with other pages, the pages will be played according to the page order from top to bottom.

    ...
